HAN (Hybrid Access Node)

Please also Check


HAN Form Factor			HAN Power Output
Model	Image	Vol.	48V DC+ / 150W	48 VDC+ / 300W & 24 VDC+ / 30W	24 VDC+ / 150W	Passive
P-HAN E1		1L	x	x	x	HNCD5071070/1
P-HAN E10		10L	x	x	x	HNCD520242/P1
A-HAN E3		3L	HNCD520252/1	New HAN Power Card in Final Testing Expected Launch Q4 2026	SO	x
A-HAN E10		10L	HNCD520242/1		HNCD520242/1D LL	x
A-HAN E10s		10L	HNCD520242/70		SO	x
A-HAN E10t		10L	HNCD520242/80 LL		SO	x
A-HAN E10st	NA	10L	SO		SO	x
A-HAN E10m		10L	SO		SO	x
A-HAN E10sm	NA	10L	SO		SO	x

P-HAN : HAN i.e. Passive HAN (HAN does not have any voltage regulator)

A -HAN : Active HAN that includes DC to DC voltage regulator with the indicated capacity .

HAN : If in any document HAN appears without prefix then it is an Active HAN

s : Safe HAN ( HAN is fitted with Assa lock, also has mounting for magnetic sensor and seismic sensor)

t : Tactical HAN ( HAN is fitted with a Hybrid Expanded Beam Bulkhead to be used with deployable Tactical Cables)

m : M12 connectors ( HAN fitted with external M12 ethernet connectors on the side of the HAN)

LL : Possible long lead time on this item

+ : HAN can be switched to "+" mode to enable 10% extra voltage on the regulated output voltage

Vol. : Internal Volume of the HAN in liters

x : Product not available

SO : Special Order ( Non standard item, can be produced based on special order and subject to MOQ. Long lead time may apply)

NA : Information not available

The InOne HAN (Hybrid Access Node) model selection table
